AZDye 488 Biotin (CCT-1395)

Description

AZDye™ 488 Biotin can be used for detecting and quantifying biotin binding sites of avidin, streptavidin or neutravidin. This reagent overcomes major shortcomings of commonly used Biotin-4-fluorescein – poor solubility in aqueous media and pH dependent absorbance and emission. AZDye™ 488 Biotin is a water soluble reagent and its green fluorescence is pH independent from pH 4 to pH 10. A flexible PEG3 spacer between biotin moiety and fluorescent tag minimize steric hindrance involved in binding to avidin, streptavidin or neutravidin.

AZDye™ 488 is a bright, and highly photostable, green-fluorescent probe optimally excited by the 488 nm laser line. This probe is water-soluble and its fluorescence is pH independent over a wide pH range. The brightness and photostability of blue dyes are best suited to direct imaging of low-abundance targets.

AZDye™ 488 is structurally identical to Alexa Fluor® 488. Its absorption/emission spectra is a perfect match to spectra of many other fluorescent dyes based on sulfonated rhodamine 110 core, including DyLight® 488, Alexa Fluor® 488, and CF® 488A.

DyLight® and Alexa Fluor® are a registered trademark of Thermo Fisher Scientific.

Specifications

Unit Size1 mg, 5 mg
Abs/Em Maxima494/517 nm
Extinction Coefficient
73,000
Flow Cytometry Laser Line
488 nm
Microscopy Laser Line
488 nm
Spectrally Similar DyesFAM, Alexa Fluor® 488, Atto™ 488, CF® 488A Dye, DyLight® 488
Molecular weight935.00 (protonated)
CASN/A
SolubilityWater, DMSO, DMF
Purity>95% (HPLC)
AppearanceOrange to light red solid
Storage Conditions-20°C. Desiccate
Shipping ConditionsAmbient temperature

Abs/Em Spectra

Af Af Vectorlabs

Applicable patents and legal notices are available at legal notices.
